| Dimension | Range (in mm) |
|---|---|
| Bore dia. | 60 to 160 |
| Total length | 100 to 400 |
| Micro Structure | |
|---|---|
| Graphite type | "A" & "B" ("D" & "E" Random) |
| Flake size | 4-7 Microns |
| Free ferrite | Less Than 5% |
| Matrix | Lamellar Pearlite |
| Chemical composition | Minimum | Maximum |
|---|---|---|
| Carbon | 2.90 | 3.50 |
| Silicon | 1.80 | 2.50 |
| Manganese | 0.60 | 1.00 |
| Phosphorus | 0.20 | 0.50 |
| Chromium | 0.20 | 0.50 |
| Sulphur | 0.00 | 0.12 |
| Moly | As Required | |
| Copper | As Required | |
| Nickel | As Required | |
| Boron | As Required | |
| Vanadium | As Required | |
| Hardness (BHN) | 210 to 280 |
|---|---|
| Tensile | 210 to 275 n/mm2 |
| Production Capacity | 150000+ pieces per month |
|---|---|
| Finishes | Semi-finished & fully-finished |
| ANDORIA | HANOMAG | MITSUBISHI |
| ASIA | HENSCHEL | MORGAN |
| AUDI | HILLMAN | MORRIS GARAGES |
| AUSTIN | HINO | MWM |
| BEDFORD | HONDA | NAVISTAR |
| BELARUS | HYUNDA | NISSAN |
| BENDIX | INTERNATIONAL (IHC) | OPEL |
| BMC | ISUZU | PEGASO |
| CASE | IVECO | PERKINS |
| CATERPILLAR | JAGUAR | PETTER |
| CBT | JEEP | RENAULT |
| CHEVROLET | JOHN DEERE | ROLLS ROYCE |
| CHRYSLER | KAMAZ | ROVER |
| CITRON | KARAZ | RVI |
| CLAYTON | KIA | SAVIEM |
| COMMER | KOMATSU | SCANIA |
| CUMMINS | KUBOTA | SEAT |
| DAEWOO | LADA | SHAKTIMAN |
| DAF | LANCIA | SIMCA |
| DAIHATSU | LAND ROVER | SINGER |
| DAIMLER BENZ | LEYLAND | STEYR |
| DAMAS | LIAZ | SUZUKI |
| DAVID BROWN | LISTER | TALBOT |
| DETROIT DIESEL | LOMBARDINI | TATA |
| DEUTZ | LOTUS | TATRA |
| DONGFENG | MACK | TOYOTA |
| DORMAN | MAN | TRIUM |
| FIAT | MARUTI | URSUS |
| FORD | MASSEY FERGUSON | VAUXHALL |
| FORDSON MAJOR | MERCEDES | VOLKSWAGEN |
| GARDNER | MG | VOLVO |
JK METAL CAST giant strides across globe, putting its products into the hands of customers located in the far corners of the world. Becoming the supplier of choice, delivering premium products and services, and creating value for our customers.
